Sol-Ark 5,000W All-In-One Hybrid Inverter

Name: Sol-Ark 5,000W All-In-One Hybrid Inverter
Brand: Sol-Ark
Price: 2799.00 CAD
Availability: InStock

Vendor: Sol-Ark

SKU: SA-5K-1P

LOW PRICE GUARANTEE As Canada’s #1 off-grid provider, we won’t be beat on price.

Submit Form Terms

Buy now, Pay later! Just select or at checkout! Learn more

$2,799.00 CAD

$2,799.00 CAD ~~$4,999.00 CAD~~

Shipping calculated at checkout.

Sol-Ark 5K Pre-Wired Hybrid Inverter System

5,000W All-In-One Hybrid Inverter

- High-Efficiency Intelligent Power Routing -

An all-in-one pre-wired solution that includes an inverter, charge controller, and interactive touchscreen display with remote monitoring—making off-grid installations simple.

Whether configured for Grid-tied, pure Off-Grid, or critical battery backup systems, this intelligent, transformerless DC system effortlessly manages power distribution to and from solar arrays, battery banks, local utility grids, household loads, and standby generators.

IP65 / NEMA 3R Outdoor Certified Protection Shield

Documentation

Product Manual Brochure Spec Sheet Certifications

Core Performance Benefits

Big Power, Lightweight Design Enjoy full-tier hybrid inverter capacities packaged inside a structural footprint boasting 33% less mechanical weight.

Perfect for 120V Setups Optimized specifically for true single-phase 120V off-grid networks, removing unnecessary split-phase hardware overhead.

120V Generator Compatible Natively supports automated, seamless load-shedding and charging integration directly with standard 120V backup generator units.

5.0ms Blazing Transfer Time Ultra-fast auto-switchover guarantees your home electronics and servers stay online without experiencing reboot glitches.

Technical Specifications

Mechanical Characteristics
Manufacturer	Sol-Ark
Model SKU	SA-5K-1P-N
Continuous Output	4,800W
Inverter Dimensions	579 x 330 x 231 mm
Device Weight	28.12 kg (62 lbs)
Standard Warranty	5 Years
Enclosure Shielding	IP65 / NEMA 3R
Thermal System Range	-25°C to 60°C

DC Input Specifications
Inverter Technology	Transformerless DC
Max. DC Power Rating	10,400W
Max. DC input Voltage	500V
Max. DC Input Current	40A
DC Start-up Voltage	150V
DC String Inputs	4 Inlets
MPP Trackers	2 Trackers
Max. Power per MPPT	5,200W

AC Output & Grid Details
AC Power Rating	4,800W
Nominal AC Voltage	120V L1/N/G
AC Grid Voltage Range	114V - 123V
Nominal Frequency	60 Hz (55-65 Range)
Max. Output Current	40A
Max. AC Line Current	50A
AC Wiring Gauge	8 AWG - 6 AWG

Device Features & Standards
Efficiency Peak	97.6% (Transformerless)
MPPT Voltage Limits	125V - 425V Range
DC Disconnect Method	Integrated DC Switch
Safety Protections	Reverse-Polarity Active
Night Idle Power	60W Sleep Draw
User Display Interface	LCD Touch Screen Control
Local Communication	Wi-Fi, LAN, CanBus, RS485
Code Certifications	UL1741, IEEE1547a, FCC 15
